China high quality and hot sale 35mm2 resistance welding cable

FOB Reference Price:Get Latest Price
$1.00 - $100.00 / Meter | 1000 Meter/Meters (Min. Order)
Lead Time:
Quantity(Meters) 1 - 5000 >5000
Est. Time(days) 2 Negotiable
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Henan, China
Brand Name:
Aobest
Model Number:
cu/rubber/rubber
Type:
Low Voltage
Application:
Industrial
Conductor Material:
Copper
Jacket:
Rubber
Insulation Material:
Rubber
Product name:
China high quality and hot sale 35mm2 resistance welding cable
Certificate:
ISO9001/ISO14001 /OHSAS18001/CCC
Color:
Black
Standard:
BS IEC ASTM DIN
Conductor:
Copper Core
Insulation:
Rubber Insulation
Sheath:
Rubber Sheath
MOQ:
1000 Meters
production time:
10days
delivery time:
15days
Supply Ability
Supply Ability:
50 Meter/Meters per Month
Packaging & Delivery
Packaging Details
export standard by coil or steel-wooden drum
Port
Shanghai
Lead Time :
Quantity(Meters) 1 - 5000 >5000
Est. Time(days) 2 To be negotiated
Company Information

 Zhengzhou Aobest Electronic Technology Co., Ltd. is a professional company, located in Zhengzhou, China. We provide power cables and wires.


Our main products: High and low voltage XLPE insulated Cables, PVC insulated cables, steel wire armored cables, steel tape armored cables, ABC cables, Overhead insulated cables, AAC, AAAC & ACSR cables, Copper wires, Galvanized steel wire strands, PVC insulated wires and flexible wires, Rubber insulated cables, underground cables, control cables, aluminum sheets, etc.
2017 hot selling and high quality 25mm ACSR Cable for south America
Product Description



China high quality and hot sale 35mm2 resistance welding cable

Class 6 extra flexible plain copper conductor to BS EN 60228:2005 (previously BS6360). (Class 5 flexible plain copper conductors for 120mm² and above)

Separator:
PETP (Polyethylene Terephthalate) tape
Insulation:
EPR (Ethylene Propylene Rubber) to BS7655
Sheath:
HOFR (Heat and Oil Resistant and Flame Retardant)to BS7655
Sheath Colour:Black
Voltage Rating:
100V (450V for non-welding applications if suitably protected from mechanical damage)
Temperature Rating:-20°C to +85°C
Minimum Bending Radius:6 x overall diameter
RoHS Compliant0361TQ Black Welding Cable to BS638



No. of Cores x Nominal Cross Sectional Area # x mm²Nominal Thickness of Insulationmm Overall Diameter mm Nominal Weightkg/Km
1 x 160.99.7215
1 x 250.911.2305
1 x 350.912.4400
1 x 500.914.3587
1 x 700.916.3775
1 x 951.018.61040
1 x 1201.020.31256
1 x 1501.122.61360
1 x 1851.224.71875
1 x 2401.327.82534
Packaging & Shipping

  1:standard export  wooden drum/steel wooden drum

2: upon your request

        2017 hot selling and high quality 25mm ACSR Cable for south America

Our Services



  • Any inquiries will be replied within 24 hours.
  •  OEM/ODM available.

     1) Printing your logo on the cable.

     2) Printing your logo on the pull box, wooden drum according to your design

     3) Any your idea on cable, packing box are available.

  • High quality, reasonable and competitive price, fast lead time.
  •  Good after-Sale Service.

    1) All products will have been strictly Quality Checked in house before packing.

    2) All products will be well packed before shipping.

  •  Faster delivery.:Sample order in stock, and 3-7 days for bulk production.
  • Strong technical support (technical data, drawing, etc.)
  •  Free sample is available with economic express fee.
  • Payment:We can accept payment methods: L/C, T/T, Western Union,other payment can negotiation.
Certifications



          2017 hot selling and high quality 25mm ACSR Cable for south America

FAQ



  • Q: Could you offer the Type Test Report?
  • A  -Yes, we could offer the Type Test Report issued by Chinese laboratories.
  • Q:Have you ever supplied the cables to our country?
  • A:  -Our cables have been supplied to many countries and regions, such as, Singapore, Taiwan, Hong Kong, Kenya, Congo, France, Cyprus, Honduras, etc.
  • Q: According to which standards can you produce cables?
  • A:   -GB/T, IEC, EN.
  • Q: What is your MOQ?
  • A:    -The MOQ is different, as the different cable type.
  • Q: Do you have ready cables?
  • A:  -Some normal cables have the inventory, most cables are produced according to your requirements.
  • Q: What's the tolerance of delivery length for each coil?
  •  A:   -±0.005m.
  • Q: What are your main products?
  • A:  -Our main products are the PVC insulated cable, power cable, and electric wire.
